Type/Service Location:
select
 Application:
select
Commercial & Industrial, Model Search List

Model

Model Description
Drawings
Revit/DWG
Drive
Type
Min
Flow
Max
Flow
Min
Pressure
Max
Pressure
Max
Temperature

Commercial & Industrial, Model Search List
ROOF EXHAUST CENTRIFUGAL

General Ventilation; Downblast; Round Hood
PVBelt Drive Centrifugal Roof Downblast Exhauster17/34Belt52 cfm40608 cfm0.000 in wg2.000 in wg135 F
PRNDirect Drive Centrifugal Roof Exhauster22/40Direct0 cfm2770 cfm0.000 in wg1.250 in wg135 F
PVDDirect Drive Centrifugal Roof Downblast Exhauster0/0Direct0 cfm6800 cfm0.000 in wg2.625 in wg135 F

General Ventilation; Upblast; General Ventilation
PNURFBelt Drive Centrifugal Upblast Roof Exhauster21/42Belt117 cfm33374 cfm0.000 in wg5.000 in wg300 F
PDURFDirect Drive Centrifugal Upblast Roof Exhauster18/18Direct0 cfm8248 cfm0.000 in wg1.800 in wg300 F

General Ventilation; Discharge-TH,UB, etc.; Centrifugal Blower
3000C1Single-Width Backward Inclined Belt Drive Class 10/0Belt0 cfm61128 cfm0.000 in wg5.500 in wg300 F
3000C2Single-Width Backward Inclined Belt Drive Class 20/0Belt0 cfm81504 cfm0.000 in wg11.000 in wg300 F
8100C1Single-Width Airfoil Centrifugal Belt Drive Class 1 (UL-762 Grease Rated)0/0Belt0 cfm78977 cfm0.000 in wg6.500 in wg300 F
8100C2Single-Width Airfoil Centrifugal Belt Drive Class 2 (UL-762 Grease Rated)0/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRBelt Drive Utility Blower (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F
QBRDDirect Drive Utility Blower6/0Direct0 cfm6756 cfm0.000 in wg3.250 in wg250 F

General Ventilation; Upblast; High Pressure
2100VC1Belt Drive InLine Airfoil Vertical Centrifugal Fan Class 10/0Belt663 cfm45182 cfm0.000 in wg6.000 in wg300 F
2100VC2Belt Drive InLine Airfoil Vertical Centrifugal Fan Class 20/0Belt663 cfm57072 cfm0.000 in wg9.000 in wg300 F

General Ventilation; Downblast; Square Hood
PLBelt Drive Centrifugal Roof Downblast Exhauster14/28Belt200 cfm31810 cfm0.000 in wg1.000 in wg135 F

General Ventilation; Downblast; Louvered Hood
PLZBelt Drive Centrifugal Roof Louvered Exhauster14/0Belt200 cfm31810 cfm0.000 in wg1.000 in wg135 F

Restaurant; Upblast Restaurant Grease; UL762
PNURGBelt Drive Centrifugal Upblast Roof Exhauster (UL-762 Grease Rated)21/42Belt117 cfm33374 cfm0.000 in wg5.000 in wg300 F
PDURGDirect Drive Centrifugal Upblast Roof Exhauster (UL-762 Grease Rated)17/0Direct0 cfm5317 cfm0.000 in wg1.800 in wg300 F

Restaurant; Centrifugal Blower; Discharge Upblast, UL762
8100C1Single-Width Airfoil Centrifugal Belt Drive Class 1 (UL-762 Grease Rated)0/0Belt0 cfm78977 cfm0.000 in wg6.500 in wg300 F
8100C2Single-Width Airfoil Centrifugal Belt Drive Class 2 (UL-762 Grease Rated)0/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRBelt Drive Utility Blower (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Smoke; Upblast; UL Smoke Exhaust Rated
PNUSEBelt Drive Centrifugal Upblast Roof Smoke Exhauster21/42Belt117 cfm33374 cfm0.000 in wg5.000 in wg300 F

Laboratory Exhaust; Upblast Centrifugal; Laboratory Exhaust
TIBLEBelt Drive Centrifugal Upblast Fume Lab Exhauster19/0Belt283 cfm17500 cfm0.000 in wg5.000 in wg200 F

Laboratory Exhaust; Upblast Centrifugal; Dual Laboratory Exhaust
TIBLE2FBelt Drive Centrifugal Upblast Fume Lab Exhauster Dual Fans0/0Belt283 cfm35000 cfm0.000 in wg5.000 in wg200 F

Hurricane; Downblast; Round Hood
PVHBelt Drive Centrifugal Roof Hurricane Downblast Exhauster0/0Belt52 cfm19043 cfm0.000 in wg2.000 in wg135 F
PRNHDirect Drive Centrifugal Roof Exhauster Hurricane0/8Direct0 cfm2770 cfm0.000 in wg1.250 in wg135 F
PVDHDirect Drive Centrifugal Roof Downblast Exhauster Hurricane0/0Direct0 cfm6800 cfm0.000 in wg2.625 in wg135 F

Hurricane; Upblast; General Ventilation
PNURFHBelt Drive Centrifugal Upblast Roof Exhauster Hurricane16/32Belt117 cfm14622 cfm0.000 in wg5.000 in wg300 F
PDURFHDirect Drive Centrifugal Upblast Roof Exhauster Hurricane18/0Direct0 cfm8248 cfm0.000 in wg1.800 in wg300 F

Hurricane; Discharge-TH,UB, etc.; Centrifugal Blower
3000C1HSingle-Width Backward Inclined Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg5.500 in wg300 F
3000C2HSingle-Width Backward Inclined Belt Drive Class 2 Hurricane0/0Belt0 cfm36624 cfm0.000 in wg10.000 in wg300 F
8100C1HSingle-Width Airfoil Centrifugal Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg6.500 in wg300 F
8100C2HSingle-Width Airfoil Centrifugal Belt Drive Class 2 Hurricane0/0Belt0 cfm35098 cfm0.000 in wg11.000 in wg300 F
QBRHBelt Drive Utility Blower Hurricane (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Hurricane; Discharge-TH, BH, etc.; Centrifugal Blower
QBRDHDirect Drive Utility Blower Hurricane5/0Direct0 cfm7000 cfm0.000 in wg3.250 in wg250 F

Hurricane Restaurant; Roof Upblast Grease; UL762
PNURGHBelt Drive Centrifugal Upblast Roof Exhauster Hurricane (UL-762 Grease Rated)16/32Belt117 cfm14622 cfm0.000 in wg5.000 in wg300 F
PDURGHDirect Drive Centrifugal Upblast Roof Exhauster Hurricane (UL-762 Grease Rated)17/0Direct0 cfm5317 cfm0.000 in wg1.800 in wg300 F

Hurricane Restaurant; Roof Upblast Centrifugal Blower; Discharge Upblast, UL762
8100C1HSingle-Width Airfoil Centrifugal Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg6.500 in wg300 F
8100C2HSingle-Width Airfoil Centrifugal Belt Drive Class 2 Hurricane0/0Belt0 cfm35098 cfm0.000 in wg11.000 in wg300 F
QBRHBelt Drive Utility Blower Hurricane (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Hurricane Restaurant; Supply - Side Intake; Downblast Discharge - Blower
3000C1HSingle-Width Backward Inclined Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg5.500 in wg300 F
3000C2HSingle-Width Backward Inclined Belt Drive Class 2 Hurricane0/0Belt0 cfm36624 cfm0.000 in wg10.000 in wg300 F
8100C1HSingle-Width Airfoil Centrifugal Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg6.500 in wg300 F
8100C2HSingle-Width Airfoil Centrifugal Belt Drive Class 2 Hurricane0/0Belt0 cfm35098 cfm0.000 in wg11.000 in wg300 F
QBRHBelt Drive Utility Blower Hurricane (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Hurricane Smoke; Upblast; UL Smoke Exhaust Rated
PNUSEHBelt Drive Centrifugal Upblast Roof Smoke Exhauster Hurricane16/32Belt117 cfm14622 cfm0.000 in wg5.000 in wg300 F

Seismic Rated; Upblast Centrifugal; General Ventilation
PNURFSCBelt Drive Centrifugal Upblast Roof Exhauster Seismic16/0Belt117 cfm14622 cfm0.000 in wg5.000 in wg300 F
PDURFSCDirect Drive Centrifugal Roof Exhauster Seismic0/0Direct0 cfm5317 cfm0.000 in wg1.800 in wg300 F

Seismic Rated; Upblast Centrifugal; Restaurant, UL762
PNURGSCBelt Drive Centrifugal Upblast Roof Exhauster Seismic (UL-762 Grease Rated)16/0Belt117 cfm14622 cfm0.000 in wg5.000 in wg300 F
PDURGSCDirect Drive Centrifugal Upblast Roof Exhauster Seismic (UL-762 Grease Rated)17/0Direct0 cfm5317 cfm0.000 in wg1.800 in wg300 F


ROOF EXHAUST PROPELLER

General Ventilation; Downblast Propeller; Square Hood
ECBelt Drive Square Hood Exhaust Ventilator0/8Belt1000 cfm18990 cfm0.000 in wg0.500 in wg135 F
ECHBelt Drive Square Hood Exhaust Ventilator, Heavy Duty0/14Belt1200 cfm74200 cfm0.000 in wg1.100 in wg135 F

General Ventilation; Upblast Propeller; Motor & Drives in Air Stream
UBGBelt Drive Upblast Exhauster0/16Belt3769 cfm83373 cfm0.000 in wg0.750 in wg135 F
UDDirect Drive Upblast Exhauster0/14Direct2560 cfm31988 cfm0.000 in wg0.500 in wg135 F

General Ventilation; Upblast Propeller; Motor/Drives Out of Air Stream
UBGMXBelt Drive Upblast Exhauster0/16Belt3864 cfm78842 cfm0.000 in wg0.750 in wg200 F

General Ventilation; Steel Upblast Prop; Motor/Drives Out of Air Stream
UBHBelt Drive Upblast Exhauster0/18Belt1757 cfm61236 cfm0.000 in wg1.500 in wg200 F

General Ventilation; Alum Upblast Prop; Motor/Drives Out of Air Stream
UBHABelt Drive Upblast Exhauster, Aluminum0/0Belt1757 cfm41580 cfm0.000 in wg1.000 in wg200 F

General Ventilation; Downblast Propeller; Low Pressure - Economical
LQDirect Drive Propeller Roof Exhaust Fan0/18Direct100 cfm14100 cfm0.000 in wg2.000 in wg135 F

Smoke; Motor / Drives Out Of Air Stream; UL Smoke Exhaust Rated
UBGMXSEBelt Drive Emergency Smoke Exhauster0/0Belt3864 cfm78842 cfm0.000 in wg0.750 in wg200 F

Smoke; Motor / Drives Out Of Air Stream; UL Smoke Exhaust Rated
UBHSEBelt Drive Upblast Smoke Exhauster0/0Belt1757 cfm61236 cfm0.000 in wg1.500 in wg200 F


ROOF SUPPLY CENTRIFUGAL

General Ventilation; Side Intake; General Ventilation / Restaurant
AFSIFiltered Supply Roof Ventilator0/10Belt0 cfm14000 cfm0.000 in wg2.750 in wg135 F

General Ventilation; 4-Side Intake; General Ventilation / Restaurant
AFSNFiltered Supply Standard Hood Roof Ventilator0/10Belt535 cfm14000 cfm0.000 in wg3.000 in wg135 F

General Ventilation; Louvered / 4-Side Intake; General Ventilation / Restaurant
AFSLFiltered Supply Louver Roof Ventilator0/10Belt0 cfm14000 cfm0.000 in wg3.000 in wg135 F

General Ventilation; Side Intake; General Ventilation / Restaurant
3000C1Single-Width Backward Inclined Belt Drive Class 10/0Belt0 cfm61128 cfm0.000 in wg5.500 in wg300 F
3000C2Single-Width Backward Inclined Belt Drive Class 20/0Belt0 cfm81504 cfm0.000 in wg11.000 in wg300 F
8100C1Single-Width Airfoil Centrifugal Belt Drive Class 1 (UL-762 Grease Rated)0/0Belt0 cfm78977 cfm0.000 in wg6.500 in wg300 F
8100C2Single-Width Airfoil Centrifugal Belt Drive Class 2 (UL-762 Grease Rated)0/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRBelt Drive Utility Blower (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

General Ventilation; Side Intake; General Ventilation
QBRDDirect Drive Utility Blower6/0Direct0 cfm6756 cfm0.000 in wg3.250 in wg250 F

Restaurant; Side Intake; General Ventilation / Restaurant
AFSIFiltered Supply Roof Ventilator0/10Belt0 cfm14000 cfm0.000 in wg2.750 in wg135 F

Restaurant; 4-Side Intake; General Ventilation / Restaurant
AFSNFiltered Supply Standard Hood Roof Ventilator0/10Belt535 cfm14000 cfm0.000 in wg3.000 in wg135 F

Restaurant; Louvered / 4-Side Intake; General Ventilation / Restaurant
AFSLFiltered Supply Louver Roof Ventilator0/10Belt0 cfm14000 cfm0.000 in wg3.000 in wg135 F

Restaurant; Side Intake; Downblast Discharge - Blower
3000C1Single-Width Backward Inclined Belt Drive Class 10/0Belt0 cfm61128 cfm0.000 in wg5.500 in wg300 F
3000C2Single-Width Backward Inclined Belt Drive Class 20/0Belt0 cfm81504 cfm0.000 in wg11.000 in wg300 F
8100C1Single-Width Airfoil Centrifugal Belt Drive Class 1 (UL-762 Grease Rated)0/0Belt0 cfm78977 cfm0.000 in wg6.500 in wg300 F
8100C2Single-Width Airfoil Centrifugal Belt Drive Class 2 (UL-762 Grease Rated)0/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRBelt Drive Utility Blower (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Hurricane; Side Intake; Downblast Discharge - Blower
3000C1HSingle-Width Backward Inclined Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg5.500 in wg300 F
3000C2HSingle-Width Backward Inclined Belt Drive Class 2 Hurricane0/0Belt0 cfm36624 cfm0.000 in wg10.000 in wg300 F
8100C1HSingle-Width Airfoil Centrifugal Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg6.500 in wg300 F
8100C2HSingle-Width Airfoil Centrifugal Belt Drive Class 2 Hurricane0/0Belt0 cfm35098 cfm0.000 in wg11.000 in wg300 F
QBRHBelt Drive Utility Blower Hurricane (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Hurricane; Discharge-TH,UB, etc.; Downblast Discharge - Blower
QBRDHDirect Drive Utility Blower Hurricane5/0Direct0 cfm7000 cfm0.000 in wg3.250 in wg250 F


ROOF SUPPLY PROPELLER

General Ventilation; Round Hood; Economical Direct Drive
LQ-SDirect Drive Propeller Roof Supply Fan0/16Direct200 cfm13500 cfm0.000 in wg1.250 in wg135 F

General Ventilation; Square Hood; Medium to High Pressure
ECH-SBelt Drive Square Hood Supply Ventilator, Heavy Duty0/0Belt1200 cfm73700 cfm0.000 in wg1.100 in wg135 F

General Ventilation; Square Hood; Low Pressure
EC-SBelt Drive Square Hood Supply Ventilator0/0Belt1000 cfm18950 cfm0.000 in wg0.500 in wg135 F


ROOF/WALL GRAVITY VENTS (HOODS)

General Ventilation; Intake; Square Hood
IVIntake Gravity Vent0/0 0 cfm67358 cfm0.000 in wg0.250 in wg200 F

General Ventilation; Intake; Louvered Hood
LIVLouvered Gravity Intake Vent0/0 0 cfm85765 cfm0.000 in wg0.250 in wg200 F

General Ventilation; Exhaust (Relief)/ Intake (Supply); Round Hood
LQVGravity Relief Vent0/22 0 cfm17300 cfm0.000 in wg0.250 in wg200 F
LQV-SGravity Supply Vent0/0 0 cfm0 cfm0.000 in wg0.000 in wg0 F

General Ventilation; Exhaust (Relief); Square Hood
EVExhaust Gravity Vent0/0 0 cfm63000 cfm0.000 in wg0.250 in wg200 F

General Ventilation; Exhaust (Relief); Louvered Hood
LEVLouvered Gravity Exhaust Vent0/0 0 cfm85765 cfm0.000 in wg0.250 in wg200 F

General Ventilation; Exhaust (Relief); Upblast (Butterfly Dampers)
UBGECVent, Upblast0/0 0 cfm56548 cfm0.000 in wg0.250 in wg200 F

General Ventilation; Exhaust (Relief); Roof Vent Cap
L/LL CAPRoof Caps (Former VQ/VQL model)0/0 0 cfm810 cfm0.000 in wg0.250 in wg200 F

General Ventilation; Exhaust (Relief); Wall Vent Cap
L/LL WCPWall Caps (Former VQ/VQL model)0/0 0 cfm1070 cfm0.000 in wg0.250 in wg200 F

Hurricane; Intake; Square Hood
TIVIntake Gravity Vent Hurricane (IVH)0/0 0 cfm0 cfm0.000 in wg0.000 in wg0 F

Hurricane; Exhaust (Relief); Square Hood
TEVExhaust Gravity Vent Hurricane (EVH)0/0 0 cfm0 cfm0.000 in wg0.000 in wg0 F


WALL EXHAUST

General Ventilation; Propeller; Panel Fan
DBBelt Drive Propeller Wall Exhaust0/0Belt0 cfm81650 cfm0.000 in wg2.000 in wg140 F
DCBelt Drive Propeller Wall Exhaust Fan1/12Belt1300 cfm27720 cfm0.000 in wg0.375 in wg135 F
DCHBelt Drive Propeller Wall Exhaust Fan, Heavy Duty0/0Belt15650 cfm77240 cfm0.000 in wg0.250 in wg135 F
DCKBelt Drive Propeller Wall Exhaust Fan0/16Belt2200 cfm73080 cfm0.000 in wg0.750 in wg135 F
KBelt Drive Propeller Wall Exhaust Fan0/16Belt590 cfm79330 cfm0.000 in wg1.250 in wg135 F
DMD-EPropeller Fan Direct Connected0/0Direct1000 cfm9478 cfm0.000 in wg0.500 in wg135 F
FNDirect Drive Propeller Wall Exhaust Fan13/18Direct0 cfm22400 cfm0.000 in wg1.000 in wg135 F
FQDirect Drive Propeller Wall Exhaust Fan, Quiet15/20Direct100 cfm17800 cfm0.000 in wg0.875 in wg135 F

General Ventilation; Propeller; Wall Housing Panel Fan
DBWBPBelt Drive Propeller Wall Box Exhaust Fan0/0Belt0 cfm81650 cfm0.000 in wg2.000 in wg140 F
DCHWBPBelt Drive Propeller Wall Box Exhaust Fan, Heavy Duty0/0Belt15650 cfm77240 cfm0.000 in wg0.250 in wg135 F
DCKWBPBelt Drive Propeller Wall Box Exhaust Fan0/16Belt2200 cfm73080 cfm0.000 in wg0.750 in wg135 F
DCWBPBelt Drive Propeller Wall Box Exhaust Fan0/12Belt1300 cfm27720 cfm0.000 in wg0.375 in wg135 F
KWBPBelt Drive Propeller Wall Box Exhaust Fan0/12Belt590 cfm47400 cfm0.000 in wg1.250 in wg135 F
FNWBPDirect Drive Propeller Wall Box Exhaust Fan13/16Direct0 cfm22400 cfm0.000 in wg1.000 in wg135 F
FQWBPDirect Drive Propeller Wall Box Exhaust Fan, Quiet15/20Direct150 cfm17800 cfm0.000 in wg0.875 in wg135 F

General Ventilation; Propeller; Wall Collar Panel Fan
DBWCPBelt Drive Propeller Wall Collar Exhaust Fan0/0Belt0 cfm81650 cfm0.000 in wg2.000 in wg140 F
DCHWCPBelt Drive Propeller Wall Collar Exhaust Fan, Heavy Duty0/10Belt15650 cfm77240 cfm0.000 in wg0.250 in wg135 F
DCKWCPBelt Drive Propeller Wall Collar Exhaust Fan0/16Belt2200 cfm73080 cfm0.000 in wg0.750 in wg135 F
DCWCPBelt Drive Propeller Wall Collar Exhaust Fan0/12Belt1300 cfm27720 cfm0.000 in wg0.375 in wg135 F
KWCPBelt Drive Propeller Wall Collar Exhaust Fan0/0Belt590 cfm47400 cfm0.000 in wg1.250 in wg135 F
FNWCPDirect Drive Propeller Wall Collar Exhaust Fan13/16Direct0 cfm22400 cfm0.000 in wg1.000 in wg135 F
FQWCPDirect Drive Propeller Wall Collar Exhaust, Quiet15/19Direct150 cfm17800 cfm0.000 in wg0.875 in wg135 F

General Ventilation; Centrifugal; General Ventilation Wall Fan
PNURFWBelt Drive Centrifugal Upblast Wall Exhauster16/32Belt117 cfm14622 cfm0.000 in wg5.000 in wg300 F
PDURFDirect Drive Centrifugal Upblast Roof Exhauster18/18Direct0 cfm8248 cfm0.000 in wg1.800 in wg300 F

General Ventilation; Propeller; Aluminum Panel Fan
DCABelt Drive Propeller Wall Fan Aluminum0/0Belt1300 cfm27720 cfm0.000 in wg0.300 in wg13 F

General Ventilation; Propeller; Slanted Wall Housing
DCWSBelt Drive Propeller Slant Wall Housing Fan0/0Belt1300 cfm27720 cfm0.000 in wg0.375 in wg135 F

Restaurant; Centrifugal Wall Exhaust; Restaurant, UL762
PNURGWBelt Drive Centrifugal Upblast Wall Exhauster (UL-762 Grease Rated)16/32Belt117 cfm14622 cfm0.000 in wg5.000 in wg300 F
PDURGDirect Drive Centrifugal Upblast Roof Exhauster (UL-762 Grease Rated)17/0Direct0 cfm5317 cfm0.000 in wg1.800 in wg300 F

Restaurant; Centrifugal Blower; Wall Exhaust, TH, BH Discharge UL762
8100C1Single-Width Airfoil Centrifugal Belt Drive Class 1 (UL-762 Grease Rated)0/0Belt0 cfm78977 cfm0.000 in wg6.500 in wg300 F
8100C2Single-Width Airfoil Centrifugal Belt Drive Class 2 (UL-762 Grease Rated)0/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRBelt Drive Utility Blower (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Smoke; Wall Discharge; UL Smoke Exhaust Rated
PNUSEWBelt Drive Centrifugal Upblast Wall Smoke Exhauster13/26Belt117 cfm11110 cfm0.000 in wg5.000 in wg300 F


WALL SUPPLY

General Ventilation; Propeller; Panel Fan
DC-RBelt Drive Propeller Wall Supply Fan0/10Belt1300 cfm27720 cfm0.000 in wg0.375 in wg135 F
DCH-RBelt Drive Propeller Wall Supply Fan, Heavy Duty0/0Belt15650 cfm77240 cfm0.000 in wg0.250 in wg135 F
DCK-RBelt Drive Propeller Wall Supply Fan0/16Belt2200 cfm73080 cfm0.000 in wg0.750 in wg135 F
K-RBelt Drive Propeller Wall Supply Fan0/10Belt590 cfm36870 cfm0.000 in wg1.250 in wg135 F
FN-RDirect Drive Propeller Wall Supply Fan14/18Direct250 cfm22400 cfm0.000 in wg1.000 in wg135 F
FQ-RDirect Drive Propeller Wall Supply Fan, Quiet13/16Direct300 cfm17800 cfm0.000 in wg0.875 in wg135 F

General Ventilation; Propeller; Wall Housing Panel Fan
DC-RWBPBelt Drive Propeller Wall Box Supply Fan0/10Belt1300 cfm27720 cfm0.000 in wg0.375 in wg135 F
DCH-RWBPBelt Drive Propeller Wall Box Supply Fan, Heavy Duty0/0Belt15650 cfm77240 cfm0.000 in wg0.250 in wg135 F
DCK-RWBPBelt Drive Propeller Wall Box Supply Fan0/16Belt2200 cfm73080 cfm0.000 in wg0.750 in wg135 F
K-RWBPBelt Drive Propeller Wall Box Supply Fan0/10Belt590 cfm36870 cfm0.000 in wg1.250 in wg135 F
FN-RWBPDirect Drive Propeller Wall Box Supply Fan13/18Direct250 cfm22400 cfm0.000 in wg1.000 in wg135 F
FQ-RWBPDirect Drive Propeller Wall Box Supply Fan, Quiet13/16Direct300 cfm17800 cfm0.000 in wg0.875 in wg135 F

General Ventilation; Centrifugal; TH, BH Discharge - Blower
3000C1Single-Width Backward Inclined Belt Drive Class 10/0Belt0 cfm61128 cfm0.000 in wg5.500 in wg300 F
3000C2Single-Width Backward Inclined Belt Drive Class 20/0Belt0 cfm81504 cfm0.000 in wg11.000 in wg300 F
8100C1Single-Width Airfoil Centrifugal Belt Drive Class 1 (UL-762 Grease Rated)0/0Belt0 cfm78977 cfm0.000 in wg6.500 in wg300 F
8100C2Single-Width Airfoil Centrifugal Belt Drive Class 2 (UL-762 Grease Rated)0/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRBelt Drive Utility Blower (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F
QBRDDirect Drive Utility Blower6/0Direct0 cfm6756 cfm0.000 in wg3.250 in wg250 F

General Ventilation; Propeller; Wall Collar Panel Fan
DC-RWCPBelt Drive Propeller Wall Collar Supply Fan0/10Belt1300 cfm27720 cfm0.000 in wg0.375 in wg135 F
DCH-RWCPBelt Drive Propeller Wall Collar Supply Fan, Heavy Duty0/10Belt15650 cfm77240 cfm0.000 in wg0.250 in wg135 F
DCK-RWCPBelt Drive Propeller Wall Collar Supply Fan0/16Belt2200 cfm73080 cfm0.000 in wg0.750 in wg135 F
K-RWCPBelt Drive Propeller Wall Collar Supply Fan0/0Belt590 cfm36870 cfm0.000 in wg1.250 in wg135 F
FN-RWCPDirect Drive Propeller Wall Collar Supply Fan12/18Direct250 cfm22400 cfm0.000 in wg1.000 in wg135 F
FQ-RWCPDirect Drive Propeller Wall Collar Supply, Quiet13/16Direct300 cfm17800 cfm0.000 in wg0.875 in wg135 F


CEILING & CABINET FANS

General Ventilation; Ceiling Mount (Intake); Low Pressure - Economical
LCeiling Exhauster (Former VQ)0/24Direct12 cfm722 cfm0.000 in wg1.000 in wg135 F
ORTECHESCeiling Exhauster (Former VQES)0/0Direct0 cfm171 cfm0.000 in wg0.830 in wg135 F

General Ventilation; In-Line Ceiling Exhauster; Low Pressure - Economical
LLInline & Cabinet Exhauster (Former VQL)0/24Direct16 cfm700 cfm0.000 in wg1.000 in wg135 F

General Ventilation; Ceiling Duct Blower; Indoor Only
DMSingle Forward Curved Inline Duct Blowers Indoor0/0Belt300 cfm7600 cfm0.000 in wg2.500 in wg250 F
DMT Twin Forward Curved Inline Duct Blower Indoor0/0Belt600 cfm8810 cfm0.000 in wg2.500 in wg250 F

General Ventilation; Ceiling Duct Blower; Indoor / Outdoor
DMSSingle Forward Curved Inline Duct Blowers Indoor/Outdoor0/0Belt600 cfm8500 cfm0.000 in wg2.500 in wg250 F
DMST Twin Forward Curved Inline Duct Blower Indoor/Outdoor0/0Belt1200 cfm18000 cfm0.000 in wg2.500 in wg250 F

General Ventilation; Ceiling Mount (Intake); AC to DC motor
ORTECHECCeiling Exhauster (Former VQEC)0/0Direct0 cfm505 cfm0.000 in wg0.500 in wg135 F
VQEC-FCeiling Exhauster - EC0/0Direct0 cfm200 cfm0.000 in wg0.400 in wg135 F


IN-LINE

General Ventilation; Propeller; Round Duct
HAInLine Belt Drive Tubeaxial Propeller Fan12/22Belt0 cfm63845 cfm0.000 in wg2.000 in wg200 F
HQInLine Belt Drive Low Sound Tubeaxial Propeller Fan0/0Belt0 cfm40000 cfm0.000 in wg2.000 in wg200 F
HDDDirect Drive Tubeaxial Propeller Fan0/14Direct0 cfm14792 cfm0.000 in wg0.750 in wg135 F

General Ventilation; Centrifugal; Round Duct
2100HC1Belt Drive InLine Airfoil Horizontal Centrifugal Fan Class 10/0Belt663 cfm45182 cfm0.000 in wg6.000 in wg300 F
2100HC2Belt Drive InLine Airfoil Horizontal Centrifugal Fan Class 20/0Belt663 cfm57072 cfm0.000 in wg9.000 in wg300 F
2100VC1Belt Drive InLine Airfoil Vertical Centrifugal Fan Class 10/0Belt663 cfm45182 cfm0.000 in wg6.000 in wg300 F
2100VC2Belt Drive InLine Airfoil Vertical Centrifugal Fan Class 20/0Belt663 cfm57072 cfm0.000 in wg9.000 in wg300 F
TIBCentrifugal In Line Duct Fan19/0Belt250 cfm20250 cfm0.000 in wg5.000 in wg200 F
TIBCentrifugal In Line Duct Fan19/0Belt250 cfm20250 cfm0.000 in wg5.000 in wg200 F
TIBACentrifugal In Line Duct Fan, Aluminum19/0Belt250 cfm20250 cfm0.000 in wg5.000 in wg200 F
TIBACentrifugal In Line Duct Fan, Aluminum19/0Belt250 cfm20250 cfm0.000 in wg5.000 in wg200 F

General Ventilation; Centrifugal; Square Duct - Steel Housing
XBInLine Belt Drive Square Centrifugal Duct Fan9/14Belt0 cfm28858 cfm0.125 in wg2.500 in wg200 F
XDInLine Direct Drive Square Centrifugal Duct Fan10/10Direct0 cfm5630 cfm0.000 in wg2.625 in wg140 F

General Ventilation; Centrifugal; Square Duct - Alum Housing
XBAInLine Belt Drive Square Centrifugal Duct Fan, Aluminum8/0Belt0 cfm22986 cfm0.125 in wg2.500 in wg200 F
XDAInLine Direct Drive Square Centrifugal Duct Fan, Aluminum10/0Direct0 cfm5630 cfm0.000 in wg2.625 in wg140 F

General Ventilation; Forward Curved Wheel; Low Pressure - Economical
LLInline & Cabinet Exhauster (Former VQL)0/24Direct16 cfm700 cfm0.000 in wg1.000 in wg135 F

General Ventilation; Mixed Flow; Round Duct
QBMXHIn-Line Horizontal Mixed Flow Fan0/0Belt0 cfm60349 cfm0.000 in wg5.500 in wg300 F
QBMXVIn-Line Vertical Mixed Flow Fan0/0Belt0 cfm60349 cfm0.000 in wg5.500 in wg300 F
QBMXDIn-Line Mixed Flow Direct Drive Fan0/0Direct500 cfm30600 cfm0.000 in wg4.500 in wg135 F

General Ventilation; Ceiling Duct Blower; Indoor Only
DMSingle Forward Curved Inline Duct Blowers Indoor0/0Belt300 cfm7600 cfm0.000 in wg2.500 in wg250 F
DMT Twin Forward Curved Inline Duct Blower Indoor0/0Belt600 cfm8810 cfm0.000 in wg2.500 in wg250 F

General Ventilation; Ceiling Duct Blower; Indoor / Outdoor
DMSSingle Forward Curved Inline Duct Blowers Indoor/Outdoor0/0Belt600 cfm8500 cfm0.000 in wg2.500 in wg250 F
DMST Twin Forward Curved Inline Duct Blower Indoor/Outdoor0/0Belt1200 cfm18000 cfm0.000 in wg2.500 in wg250 F

General Ventilation; Vaneaxial; Round Duct
AVDDirect Drive Vane Axial0/0Direct0 cfm100000 cfm0.000 in wg8.000 in wg135 F

General Ventilation; Propeller; Low Sound Tubeaxial
HQInLine Belt Drive Low Sound Tubeaxial Propeller Fan0/0Belt0 cfm40000 cfm0.000 in wg2.000 in wg200 F

Restaurant; Centrifugal In-Line; Restaurant, UL762
2100HIGBelt Drive InLine Airfoil Horizontal Centrifugal Fan Class 1 (UL-762 Grease Rated)0/0Belt663 cfm45182 cfm0.000 in wg6.000 in wg300 F
2100VIGBelt Drive InLine Airfoil Vertical Centrifugal Fan (UL-762 Grease Rated)0/0Belt663 cfm45182 cfm0.000 in wg6.000 in wg300 F

Restaurant; Mixed Flow In-line; UL762
QBMXHIGInLine Horizontal Grease Mixed Flow Fan0/0Belt0 cfm60349 cfm0.000 in wg5.500 in wg300 F
QBMXVIGInLine Vertical Grease Mixed Flow Fan0/0Belt0 cfm60349 cfm0.000 in wg5.500 in wg300 F

Smoke; Propeller - Round Duct; UL Smoke Exhaust Rated
HASEBelt Drive Smoke Exhaust Tubeaxial Propeller Fan0/0Belt950 cfm63845 cfm0.000 in wg2.000 in wg200 F

Smoke; Centrifugal - Round Duct; UL Smoke Exhaust Rated
2100HSEBelt Drive InLine Airfoil Horizontal Smoke Exhaust Centrifugal Fan Class 10/0Belt663 cfm45182 cfm0.000 in wg6.000 in wg300 F
2100VSEBelt Drive InLine Airfoil Vertical Smoke Exhaust Centrifugal Fan0/0Belt663 cfm45182 cfm0.000 in wg6.000 in wg300 F

Smoke; Mixed Flow - Round Duct; UL Smoke Exhaust Rated
QBMXHSEIn-Line Horizontal Smoke Exhaust Mixed Flow Fan0/0Belt0 cfm60349 cfm0.000 in wg5.500 in wg300 F
QBMXVSEInLine Vertical Smoke Exhaust Mixed Flow Fan0/0Belt0 cfm60349 cfm0.000 in wg5.500 in wg300 F

Smoke; Vaneaxial; UL Smoke Exhaust Rated
AVDSEDirect Drive Smoke Exhaust Van Axial0/0Direct0 cfm100000 cfm0.000 in wg8.000 in wg500 F


BLOWERS & PLENUM FANS

General Ventilation; Centrifugal Blower; Backwardly Inclined Airfoil
8100C1Single-Width Airfoil Centrifugal Belt Drive Class 1 (UL-762 Grease Rated)0/0Belt0 cfm78977 cfm0.000 in wg6.500 in wg300 F
8100C2Single-Width Airfoil Centrifugal Belt Drive Class 2 (UL-762 Grease Rated)0/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRBelt Drive Utility Blower (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F
QBRDDirect Drive Utility Blower6/0Direct0 cfm6756 cfm0.000 in wg3.250 in wg250 F

General Ventilation; Centrifugal Blower; Backwardly Inclined Single Thickness
3000C1Single-Width Backward Inclined Belt Drive Class 10/0Belt0 cfm61128 cfm0.000 in wg5.500 in wg300 F
3000C2Single-Width Backward Inclined Belt Drive Class 20/0Belt0 cfm81504 cfm0.000 in wg11.000 in wg300 F

General Ventilation; Centrifugal Blower; Forward Curved Wheel
FCFFC SWSI Blower0/0Belt300 cfm15000 cfm0.125 in wg4.000 in wg250 F

General Ventilation; Plenum; Steel Wheel Arrangement 3
8800HC1Airfoil Centrifugal Plenum Fan0/0Belt0 cfm30944 cfm0.000 in wg8.000 in wg300 F

General Ventilation; Plenum; Alum Star Wheel - Low Sound
8800STRHAirfoil Centrifugal Plenum W/Aluminum Star Wheel0/0Belt0 cfm79552 cfm0.000 in wg7.000 in wg135 F

General Ventilation; Open Radial Material Handling; ARR/10 SWSI
400MSingle Width Radial Blade Material Handling0/0Belt0 cfm7000 cfm0.000 in wg18.000 in wg200 F

Smoke; Blower - Multiple Discharge; UL Smoke Exhaust Rated
8100SEC1Single-Width Airfoil Smoke Exhaust Centrifugal Belt Drive Class 10/0Belt0 cfm78977 cfm0.000 in wg5.500 in wg300 F
8100SEC2Single-Width Airfoil Smoke Exhaust Centrifugal Belt Drive Class 20/0Belt0 cfm80015 cfm0.000 in wg11.000 in wg300 F
QBRSEBelt Drive Emergency Smoke Exhauster9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Hurricane; Discharge-TH, BH, etc.; Centrifugal Blower
3000C1HSingle-Width Backward Inclined Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg5.500 in wg300 F
3000C2HSingle-Width Backward Inclined Belt Drive Class 2 Hurricane0/0Belt0 cfm36624 cfm0.000 in wg10.000 in wg300 F
8100C1HSingle-Width Airfoil Centrifugal Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg6.500 in wg300 F
8100C2HSingle-Width Airfoil Centrifugal Belt Drive Class 2 Hurricane0/0Belt0 cfm35098 cfm0.000 in wg11.000 in wg300 F
QBRHBelt Drive Utility Blower Hurricane (UL-762 Grease Rated)9/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F

Hurricane; Discharge-TH,UB, etc.; Centrifugal Blower
QBRDHDirect Drive Utility Blower Hurricane5/0Direct0 cfm7000 cfm0.000 in wg3.250 in wg250 F

Hurricane Smoke; Roof Exhaust Centrifugal; UL Smoke Exhaust Rated
8100C1SHSingle-Width Airfoil Smoke Exhaust Centrifugal Belt Drive Class 1 Hurricane0/0Belt0 cfm27468 cfm0.000 in wg6.500 in wg300 F
8100C2SHSingle-Width Airfoil Smoke Exhaust Centrifugal Belt Drive Class 2 Hurricane0/0Belt0 cfm35098 cfm0.000 in wg11.000 in wg300 F
QBRSEHBelt Drive Emergency Smoke Exhauster Hurricane8/0Belt0 cfm23230 cfm0.250 in wg4.250 in wg250 F


CIRCULATORS / DOCK / MAN COOLERS

General Ventilation; Propeller; Hanging Stir Fan / ManCooler
HDDDFDirect Drive Tubeaxial Dock Fan Propeller Fan0/0Direct0 cfm3938 cfm0.000 in wg0.000 in wg135 F

General Ventilation; Circulator Fan; Indoor Only
HAFDirect Drive Horizontal Air Flow Fan0/0Direct0 cfm12280 cfm0.000 in wg0.000 in wg135 F
